Description
| Power | 21.5 hp 16.0 kW | |||
|---|---|---|---|---|
| Model number | FR651V | |||
| Displacement | 44.3 cu in. 726 cc | |||
| Cylinders | V-twin | |||
| Lubrication | Full pressure with replaceable filter, capacity, 2.2 U.S. qt 2.1 L | |||
| Type | Overhead valve | |||
| Battery | 12 V 300 CCA | |||
| Choke/speed control | Separate levers | |||
| Cooling method | Air | |||
| Fuel tank capacity | 3.0 U.S. gal. 11.4 L | |||
| Fuel gauge | Translucent tank |
| Dual hydros | Hydro-Gear EZT-C with 1-in. (2.5-cm) axles |
|---|
| Forward speed | 0-7 mph 0-11.3 km/h | |||
|---|---|---|---|---|
| Reverse speed | 0-3.5 mph 0-5.6 km/h | |||
| Speed and direction control | Twin levers | |||
| Control adjustment | 3 height, 11 positions |
| Frame | Heavy-duty 2.5-in. x 2-in. (6-cm x 5-cm) front, and 1.5-in. x 2-in. (4-cm x 5-cm) side tubing | |||
|---|---|---|---|---|
| Primer/paint | E-coat/powder | |||
| Front caster tires | 11×6-5 | |||
| Front caster bearings | Sealed ball bearings | |||
| Drive tires | 18×8.5-8 | |||
| Hour meter | Yes | |||
| Service interval decal | Yes | |||
| Storage compartment | Standard covered | |||
| Cup holder | Yes | |||
| Maximum towing capacity | 250 lb 113 kg |
| Seat back height | High back with armrests, 20 in. 51 cm | |||
|---|---|---|---|---|
| Fore-aft adjustment | 2.9 in. 7 cm | |||
| Seat suspension | Two springs |
| Type | Foot lift | |||
|---|---|---|---|---|
| Mower cut height | 1.25-4.5 in. 3-11 cm | |||
| Cut height increments | 0.25 in. 0.64 cm | |||
| Preset cut height | Yes |
| Width of cut | Accel Deep™ mower deck, 42 in. 107 cm | |||
|---|---|---|---|---|
| Type | Side discharge | |||
| Mower deck material | 12 gauge 0.105 in. 2.7 mm | |||
| Mower drive system | V-belt |
| Type | Electric, 105 lb-ft 142 Nm | |||
|---|---|---|---|---|
| Drive | V-belt |
| Wheelbase | 49.4 in. 1255 mm | |||
|---|---|---|---|---|
| Overall length | 75.4 in. 1915 mm | |||
| Width without mower | 43.3 in. 1100 mm | |||
| Width with mower | 50.4 in. 1280 mm | |||
| Width with mower (deflector raised for storage) | 46.5 in. 1180 mm | |||
| Height | 43.3 in. 1100 mm | |||
| Weight | 572 lb 260 kg |
| Rollover protective structure (ROPS) | No | |||
|---|---|---|---|---|
| Slope operating limit | 13 degrees; 10 degrees with Material Collection System | |||
| Operator presence system | Yes | |||
| Park brake interlock | Yes | |||
| Operator video | Yes, online |
| Mulching system | Optional MulchControl™ attachment | |||
|---|---|---|---|---|
| Rubber floor mat | Standard | |||
| Sun shade | Optional | |||
| Mounted sprayer | Not available | |||
| Protective cover | Optional | |||
| Light kit | Standard | |||
| Material collection system | Two-bag cut-and-throw MCS, 6.5 bu 229 L |
| Manufacturing location | Greeneville, Tennessee, USA | |||
|---|---|---|---|---|
| Date collected | 3-Oct-22 |
